RESIDENTIAL AND SMALL BUSINESS SYSTEMS: SMART HOME AUTOMATION PACK

I. Wiring Cubicle Setup

• Type: Smart Home Wiring Cubicle
• Frame: Wooden with MS structure
• Dimensions: 1.2 m (Height) × 1.2 m (Width) × 0.9 m (Depth)
• Quantity: 1 Unit (shared for 2 Packs)

II. Smart Home Automation Pack (KNX Platform)

Each KNX Pack includes the following industrial-grade, real-world automation components:

A. Power Distribution & Safety

• Residential Box with 3 Rows: 1 Nos
• Ground Leakage Circuit Breaker: 10A, 30mA – 1 Nos
• RCCB: 2P, 25A, 300mA – 1 Nos
• MCB: 6A – 1 Nos
• Contactor: 3P, NO+NC, 9A – 1 Nos
• Surge Arrestor: 1 Nos
• E-Stop Push Button (Emergency Stop): 1 Nos
• Single Phase Energy Meter: 1 Nos
• Voltage Monitoring Relay: 1 Nos
• Power Supply: REG/24V DC/0.4A – 1 Nos
• Distribution Board: 12 Way (1 Tier) – 1 Nos

B. KNX System Components

• KNX Bus Power Supply: 1 Nos
• KNX USB Interface: 1 Nos
• USB Programming Lead (KNX): 1 Nos
• 10 m EIB Cable for KNX Bus: 1 Nos
• Set of KNX Connectors and Terminal Strips: 1 Set
• KNX Programming Software (1 User License): 1 Nos

C. Input Devices (Control Interfaces)

• Multi-Function Pushbutton Unit (2 Buttons): 1 Nos
• 2-Gang Push Button Module Cover Plate: 1 Nos
• Touch Keypad with Display (Scene Control): 1 Nos
• Touch Pro Cover Plate: 1 Nos
• Presence Detector with Infrared Receiver: 1 Nos
• E-stop Module (KNX Integrated Safety): 1 Nos
• Router with Wi-Fi Support (for IP-KNX connectivity): 1 Nos

D. Output Devices (Actuators & Loads)

• Switching Actuator (4 Outputs): 1 Nos
• Dimming Actuator (4 Outputs): 1 Nos
• Blind Actuator (2 Outputs): 1 Nos
• Dimmable LED Light Fixtures: 15W with Phase-Cut Dimmable Driver – 3 Nos
• Standard On/Off LED Light Fixtures: 15W, 6000K with Driver – 5 Nos
• Blind Motor with Fabric: 1 Nos
• Metal Frame for 2-Gang Switch: 1 Nos

E. Computer-Based Programming Station

Each Pack is supported by:

• Computer System (Minimum i5, 8GB RAM, SSD): 1 Nos
• Computer Table and Ergonomic Setup: 1 Nos

III. Documentation and OEM Support

• Training Manuals (Soft Copy + Hard Copy):
  • Technical Specifications
  • Wiring Diagrams
  • Configuration Examples
  • Sample Exercises for Students
  • Application-Based Scenarios
• Certification Support:
  • Certificate of Conformity by OEM
  • OEM-backed Global Certification for Trainees
